Cohort construction with provenance

Source: vignettes/cohort.Rmd
cohort.Rmd

cohort provides one R6 class, CohortPipeline. It builds analytic cohorts with full provenance. Cohort construction stays strictly upstream of analysis. The pipeline produces analytic data tables, then hands them to whatever consumes them downstream.

A worked example

We start with a small simulated dataset.

library(cohort)
#> cohort 2026.8.6
#> https://www.rwhite.no/cohort/
library(data.table)
#>
#> Attaching package: 'data.table'
#> The following object is masked from 'package:base':
#>
#>     %notin%

set.seed(1)
d <- data.table(
  id  = 1:200,
  age = sample(c(NA, 16:80), 200, replace = TRUE),
  sex = sample(c("F", "M", NA), 200, replace = TRUE,
               prob = c(0.48, 0.48, 0.04)),
  grp = sample(c("a", "b"), 200, replace = TRUE)
)

Step 1: install a base table

cp <- CohortPipeline$new(
  d,
  cache_file = file.path(tempdir(), "cohort_cache.rds"),
  label      = "Eligible patients"
)
on.exit(cp$save(), add = TRUE)

CohortPipeline$new() makes a defensive copy of d once. The pipeline never mutates your data table, whatever operations you run on it.

The cache_file argument enables incremental re-execution. On the first run the pipeline writes a snapshot to disk. On later runs it restores the snapshot, and matching operations replay instantly with no recomputation. The label argument is the cohort’s display label in CONSORT diagrams, and defaults to "Cohort participants". The identifier "root" is universal, and code always uses it.

Step 2: apply root-level exclusions

Every exclusion takes a human-readable reason and an R expression as a string. The pipeline parses the string and evaluates it against the rows currently included on the branch.

cp$exclude_and_track("root", "Missing sex", "is.na(sex)")
cp$exclude_and_track("root", "Missing age", "is.na(age)")
cp$exclude_and_track("root", "Under 18",    "age < 18")

The pipeline treats NA predicate results as FALSE and keeps those rows. You therefore do not need a defensive !is.na(...) clause for every column.

Step 3: branch into sub-cohorts

cp$new_cohort("adults_female", from = "root", label = "Adult females")
cp$exclude_and_track("adults_female", "Not female", "sex != 'F'")

cp$new_cohort("adults_grp_a", from = "root",
              label = "Adults, group A")
cp$exclude_and_track("adults_grp_a", "Group not a", "grp != 'a'")

Your code references identifiers ("adults_female", "adults_grp_a"). Figures show labels. Call new_cohort() again with a different label. The pipeline updates the label silently and does not invalidate the cache.

A branch starts identical to its parent at the moment of branching. Sibling branches evolve independently.

The freeze rule

A cohort becomes frozen the first time either:

  1. another cohort branches from it, or
  2. an artifact is set on it.

After a cohort freezes, $exclude_and_track() on it errors. The rule guarantees that a cohort’s name maps to one definition forever. Once children depend on a cohort, its exclusion list is fixed. The practical workflow is: apply all exclusions on a cohort, then branch from it or attach artifacts. Multi-way forks are unaffected. You can branch a frozen cohort as many times as you like.

Step 4: derive cached artifacts

set_artifact() is for reusable per-cohort objects (analytic-ready data tables, summary statistics, baseline tables). Each callback receives a copy of the included rows. It also receives the named list of artifacts already attached to the cohort.

cp$set_artifact("dt_for_analysis",
  from = "adults_female",
  fn = function(dt, sib) {
    dt[, age_group := cut(age,
      breaks = c(18, 30, 50, Inf),
      right = FALSE,
      labels = c("18-29", "30-49", "50+"))]
    dt
  }
)

Each set_artifact() callback receives a fresh copy of the cohort’s included rows. It does not see changes that previous artifacts made. To chain derivations, read the previous artifact from the sib argument:

cp$set_artifact("baseline_table",
  from = "adults_female",
  fn = function(dt, sib) {
    sib$dt_for_analysis[, .(.N, mean_age = mean(age)),
      by = age_group][order(age_group)]
  }
)

Step 5: inspect the cohort tree

print(cp)
#> <CohortPipeline>
#> root: loaded = 200, included = 181, excluded = 19, 3 exclusion step(s)
#>   adults_female: branched from root at n = 181, own excluded = 93, included = 88, 1 own step(s)
#>     $ dt_for_analysis
#>     $ baseline_table
#>   adults_grp_a: branched from root at n = 181, own excluded = 93, included = 88, 1 own step(s)
cp$list_cohorts()
#>             name parent n_total n_included n_excluded n_own_steps n_artifacts
#>           <char> <char>   <int>      <int>      <int>       <int>       <int>
#> 1:          root   <NA>     200        181         19           3           0
#> 2: adults_female   root     200         88        112           1           2
#> 3:  adults_grp_a   root     200         88        112           1           0
#>    frozen
#>    <lgcl>
#> 1:   TRUE
#> 2:   TRUE
#> 3:  FALSE
cp$consort()
#>           branch parent  step      reason   expr_str n_excluded n_remaining
#>           <char> <char> <int>      <char>     <char>      <int>       <int>
#> 1:          root   <NA>     1 Missing sex is.na(sex)          8         192
#> 2:          root   <NA>     2 Missing age is.na(age)          5         187
#> 3:          root   <NA>     3    Under 18   age < 18          6         181
#> 4: adults_female   root     4  Not female sex != 'F'         93          88
#> 5:  adults_grp_a   root     4 Group not a grp != 'a'         93          88

$consort() returns a long-form table — one row per exclusion step, across every branch. Each branch contributes only its own steps. A step that a branch inherits from its parent appears under the parent.

Step 6: hand off downstream

Cached artifacts are plain R objects. Read them with $get_artifact(), then pass them to whatever consumes the analytic data.

analytic_dt <- cp$get_artifact("adults_female", "dt_for_analysis")
baseline    <- cp$get_artifact("adults_female", "baseline_table")

head(analytic_dt)
#>       id   age    sex    grp age_group
#>    <int> <int> <char> <char>    <fctr>
#> 1:     3    48      F      b     30-49
#> 2:     5    28      F      a     18-29
#> 3:     6    73      F      b       50+
#> 4:     9    68      F      a       50+
#> 5:    10    21      F      b     18-29
#> 6:    14    58      F      a       50+
baseline
#>    age_group     N mean_age
#>       <fctr> <int>    <num>
#> 1:     18-29    14 25.14286
#> 2:     30-49    30 39.80000
#> 3:       50+    44 63.54545

If you use an analysis-orchestration package, register each artifact as a named data entry — typically one short loop over cp$list_artifacts().

Schemas

Use schemas to declare a column-type contract on a branch and verify it before downstream code consumes the data.

cp$declare_schema("adults_female", schema = list(
  age = list(type = "numeric",   na = FALSE),
  sex = list(type = "character", na = FALSE)
))
cp$validate()
#> [validate] All CohortPipeline schemas passed

If a column is missing, has the wrong type, or carries unexpected NAs, $validate() throws one error that lists every problem. Pass auto_validate = TRUE to CohortPipeline$new() to fail at the failure site. Every $new_cohort() and $set_artifact() call then validates after it runs.

CONSORT diagrams

The simplest way to draw CONSORT diagrams is $plot(). With no arguments it renders one panel per cohort. Each panel walks the root-to-cohort path, and cohort names become box labels.

cp$plot()

You can name specific cohorts:

cp$plot(c("adults_female", "adults_grp_a"))

Or save to disk:

cp$plot(file = "Figure_1_CONSORT.pdf")

For full control over labels, panel titles, side branches and layout, use $draw_consort_panels() (see ?CohortPipeline).

How the cache decides what to recompute

The worked example already uses cache_file and on.exit(cp$save()). On the second run of the same script, the pipeline checks every operation against the cached log.

Method Cache key
exclude_and_track (branch, reason, expr_str)
new_cohort (name, from)
declare_schema overwrites; not cached
set_artifact (name, from, body(fn), argset)

A match advances the replay cursor with no work done. A mismatch truncates the log at that point and drops downstream artifacts. It also cascades to descendant cohorts whose inherited prefix is now stale. It then recomputes only what changed. Labels are presentation, not part of the cache key. Call new_cohort("adults_female", from = "root", label = "Adult women") again, and the pipeline updates the label. It invalidates nothing.

For set_artifact, you SHOULD use the 3-argument signature function(dt, sib, argset). Data dependencies in argset participate in the cache key. A change from argset = list(washout = 84L) to washout = 90L therefore triggers a recompute. The 2-argument form function(dt, sib) still works. It does not catch closure-captured changes.

The cache key uses body(fn) literally. If fn calls a helper that you change, the cache cannot detect the change. Either include a version tag in argset, or call cp$invalidate(cohort) to drop the cohort and force a recompute.

Mutation contract (summary)

Method Returns Mutation safe?
$get_included(c) Independent copy Yes
Callback in $set_artifact Independent copy of subset Yes
$get_everyone(c) Independent copy + status Yes

Operations that go through the public API never modify the user’s input data table or another branch.

Performance notes

  • Branching is O(n) in the number of rows of the base table. The data values themselves are stored once and shared across the tree.
  • $exclude_and_track() evaluates the predicate against the included subset only. A predicate can therefore assume that earlier exclusions already removed invalid rows.
  • The exclusion log accumulates as a list. It materializes as a data.table only on read ($consort(), $list_cohorts()). That avoids quadratic rbind growth.
